Cast Iron GGG40 - Ductile Iron

Views:12     Author:Site Editor     Publish Time: 2019-01-04      Origin:Site

Cast iron GGG40 is a low grade of ductile  iron. Our foundry has produced this material for many years, and  herein, we introduce its mechanical and chemical properties and some iron castings made by this  material grade.


GGG40 is a ductile iron grade of Germany standard, which is equal to  QT400, ASTM A536 60-40-18,  60-40-15, FCD400, GS400-12, FGS400-12, 400/17, 420/12, 400-12,  400-18 and SG38, SG40.

The Mechanical Properties of GGG40

Actually, GGG40 includes 3 types of grades. By European standard EN 1563,  they should be EN-GJS-400-15, EN-GJS-400-18, and EN-GJS-400-18LT.

Their main mechanical properties are as followings:

Grades

Tensile Strength  (Mpa)

Elongation (%)

Impact Resistance  (J)

EN-GJS-400-15

 400

 15

Not Specified

EN-GJS-400-18

 400

 18

Not Specified

EN-GJS-400-18LT

 400

 18

12J at -20°C

"LT" means for low temperature.

However, if your clients did not denote the specific requirements to  the elongation and impact resistance, then the iron foundries should meet  the lowest requirements of min. 400 Mpa tensile strength and min.  15% elongation.

The Chemical Properties of GGG40

Normally, the clients will not require the chemical composition, and  in international standards, such as ISO 1083, ASTM A536, DIN 1693,  UNI 4544 and AS 1831, there are no mandatory stipulation to the  chemical composition. Actually, from different standards, their  suggested chemical compositions are very different, but all of them  denoted that the chemical composition should just be reference, and  will not be taken as quality inspection standard.

Of course, if you need to stipulate the chemical composition to meet  the special application, then you should denote the allowable  chemical element range on the drawings or in your requirements.

The Application of GGG40

GGG40 is a very good material grade of  ductile iron, which has good tensile strength and yield  strength, and especially very high elongation rate. The higher grade  will mean the lower elongation, so GGG40 has the highest elongation  rate in all ductile iron grades.

This material is suitable for many industrial and civil fields. Such  as automotive castings, truck and agricultural parts, various  machinery casting parts, manhole covers, even for pump and valve  parts.

If you have any question about ductile iron grade for your casting requirement,please contact with us-qingdao tianhua yihe foundry, www.qdthyh.com
